Conditional HTML output, in the Views plugin, lets you display sections according to logic conditions. This is similar to if/else statements in programming languages, just without having to write PHP.

Everything you can see in the video is explained in details in the Examples section.


Setting up conditional output with the GUI

Views provides a graphical user interface for setting up conditionals, making the process easier for you. You define your conditional output by filling out relevant input fields in a GUI Dialog.

Setting up conditions with the GUI
Setting up conditions with the GUI

If you setup your conditions using the GUI:

  • you don’t have to remember the exact names of your custom fields used in your site, – the GUI will provide you with a complete list,
  • you will see a complete list of Views shortcodes that can be used in your conditions,
  • you can register your custom shortcodes and functions via the GUI,
  • and much more.

Once your condition is defined with the GUI, you can manually update it, if needed. More about setting up condition manually.

Where the GUI is available

The GUI Dialog for defining conditional output is available in all your WordPress editors.


In the WordPress native editor for posts and pages:

  • if you work in the Visual mode, locate the “if” icon (see the picture)
  • if you work in the Text mode locate the “conditional output” button


In all Toolset editors (Views (Loop Output section and Templates for This View section), Content Templates, WordPress Archive etc) locate the “conditional output” button.

Entering the condition to display

You can start defining conditions using the GUI in two ways:

  1. By selecting the conditional output first:
    1. In your editor,use your mouse to select the area you want to display conditionally. It can be any piece of content, a shortcode or a group of shortcodes.
    2. Click the “conditional output button”.
    3. Set your condition by filling out the input fields provided by the GUI.

Your output will be wrapped automatically in the conditional shortcodes.

  1. By defining the condition first
    1. In your editor, position your cursor where you want your condition output to be displayed.
    2. Press “conditional output”
    3. Set your condition by filling out the input fields provided by the GUI
    4. Add the output you want displayed conditionally.
    5. Close the condition by pressing the “/conditional output” button.

Once the GUI Dialog opens, specify your condition in the Conditions tab by filling out the inputs the GUI provides you with.


A basic condition is defined by setting up the following sections:

  • Data origin
  • Comparison
  • Value
  • Relationship

Data origin

Start defining your condition from setting up the Data origin. Data origin consists of two dropdowns. In the first one you choose custom fields, shortcodes or functions. Custom Shortcodes and Custom Functions will appear only if you have any custom shortcode/function registered in the Front-end Content tab of the Toolset Settings page. The value that appears in the second dropdown will depend on what you have selected in the first dropdown.

All options are summarized in the table below.

Table 1: Data origin section of the condition output GUI

Data origin – left dropdown Data origin – right dropdown
Types fields A list of all custom fields created in your site with the Types plugin.
Custom fields A list of native custom fields created outside the Types plugin:

  • directly using the WordPress GUI
  • by third party plugins
Views shortcodes A list of selected Views shortcodes that produce output that can be further checked for including specific content or a value.
Visit the Using shortcodes in conditions page – Views shortcodes to see examples.
Custom shortcodes A list of

  • Third Party shortcodes
  • Custom shortcodes defined by a user in PHP

registered in Toolset -> Settings -> Front-end Content tab -> Third-party shortcode arguments section.
Note: the Custom shortcodes option appears in the Data origin list only if you have at least one shortcode defined in this settings page.

Custom functions A list of

Note: The Custom functions field appears in the Data origin list only if you have at least one shortcode defined in Toolset -> Settings -> Front-end Content tab -> Functions inside conditional evaluations section.
More about using custom functions

Comparison operator

The GUI provides you with six comparison operators: =, !=, >, <, >=, <=.

Table 2: Operators that can be used in the Comparison section

Operator Description Example

A = 100, B = 200

== Checks if the values of two operands are equal or not. If the values are equal, then the condition becomes true. (A == B) is not true.
!= Checks if the values of two operands are equal or not. If the values are not equal, then the condition becomes true. (A != B) is true.
> Checks if the value of left operand is greater than the value of right operand. If yes, then the condition becomes true. (A > B) is not true.
< Checks if the value of left operand is less than the value of right operand. If yes, then the condition becomes true. (A < B) is true
>= Checks if the value of left operand is greater than or equal to the value of right operand. If yes, then the condition becomes true. (A >= B) is not true.
<= Checks if the value of left operand is less than or equal to the value of right operand. If yes, then the condition becomes true. (A <= B) is true.

Note that you can use the comparison operators with different types. You can compare:

  • strings
  • numeric values
  • boolean (true/false) values
  • date fields

Value field


Usually in the Value field you will use text or numeric constants (‘red’, 500) but you can also use custom fields and more complex expressions together with mathematical operators. This table summarizes what can be used in the Value field:

Table 3: Value section of the Condition Output GUi

Value Description Example
Empty value Leave this field empty if you want to test your field for an empty value ‘ ‘
Text String Any constant text string woman, ‘black and white’
Other field Fields defined with the Types plugin $(wpcf-employee-age)
Numeric constant Any numeric constants, including Integer and floating-point numbers 100, 3.14
Expressions You can use fields, constants and math operators to define complex expressions $(wpcf-employee-age) – ($(wpcf-work-experience))
Views functions Date filters TODAY(), MONTHS_FROM_NOW(3)

Visit the Checking Types Fields and Custom Fields page to see some examples.

Relationship

The Relationship section of the GUI allows you to evaluate more than one condition in one if-statement. With the relationship operator (AND, OR) you can combine two or more conditions:

  • the budget is greater than 1000 and the budget is less than 5000
  • the work-experience is greater than 20 or the age is greater than 40

To use more than one condition in your if-statement use the “Add another condition” button. By default the conditions are AND statements.

You can use different options in the left side dropdown of the data origin for each condition, for example Types field together with Views shortcodes:

  • the post excerpt (Views shortcode) is not empty and the gender (Types field)  equals female

Setting up conditions manually

You can also set up or update your conditions manually using the wpv-condition shortcode.

Typical cases when you will manually update your condition:

  • to add some attributes to shortcodes or custom functions used in your condition
  • to quickly add the debug attribute (to enable the debugging mode for your condition)
  • to test some special cases that are not supported by the GUI, such as checking for a featured image, taxonomy terms or to test if a post has a parent
  • to evaluate more complex expressions.

Syntax

Before Views 1.10  was released, the wpv-if shortcode was used for conditional statements. The old functionality still exists but is not recommended for new sites. For reference, visit the Legacy Support for wpv-if.

The basic syntax for wpv-conditional shortcode is the following:

The basic syntax for wpv-conditional shortcode
[wpv-conditional if="(expression)"]
	What will be done if the expression is true
[/wpv-conditional]

If the expression is true, then the meta HTML between the [wpv-conditional][/wpv-conditional] shortcodes will be executed.

The shortcode takes the following attributes:

  • if (required): it is the evaluation string and holds the actual condition to evaluate

Inside the evaluation expression, you can use any of the following:

  • Types fields
  • Custom fields
  • Views shortcodes
  • Custom shortcodes that had been already registered in Toolset -> Settings -> Front-end Content
  • Views Date filters
  • Custom functions functions that had been already registered in Toolset -> Settings -> Front-end Content
  • WordPress native functions that had been already registered in Toolset -> Settings -> Front-end Content
  • Integer and floating-point numbers
  • Strings wrapped inside single quotes
  • Math operators: +, -, *, /
  • Comparison operators: < or lt, > or gt, = or eq, <= or lte, >= or gte, != or ne
  • Boolean operators: AND, OR, NOT
The shortcode attributes
[wpv-conditional if="( $(wpcf-budget) lt '50' )" ] Your output [/wpv-conditional]
[wpv-conditional if="( '[wpv-post-excerpt]' ne '' ) AND ( $(wpcf-consultant-gender) eq 'female' )"]
Your output [/wpv-conditional]

More examples in the Example pages.

  • debug (optional): it can be set to true or false and controls whether to display debug information for administrators. The default value is false
Debug
[wpv-conditional if="( $(wpcf-budget) eq '50' )" debug="true"] Your output [/wpv-conditional]
  • evaluate (optional): it can be set to true or false and controls whether we want the condition to be met or not. The default value is true.
Evaluate
[wpv-conditional if="( $(wpcf-budget) eq '50' )" evaluate="false"] Your output [/wpv-conditional]

Debugging conditional output in Views

Debug output lets you quickly find why conditional logic isn’t doing what you expect it to do. When you enable debug output, site administrators (and only them) will see full details of the fields involved in the conditional logic and the way they are evaluated.

An example page with debug output enabled
An example page with debug output enabled

To enable debug mode, add the debug=”true” attribute to the wpv-conditional shortcode. For example:

Debugging conditional output in Views
[wpv-conditional if="( $(wpcf-budget) eq '500' )" debug="true"][/wpv-conditional]

You can also enable debug mode when you create the conditional expression. To do this, click on the Debug tab in the GUI for inserting conditional output:


Visit the “Using debug mode – example” subpage to see a detailed example.
